TS-h2490FU-7302P-128G

CPU

AMD EPYC™ 7302P 16-core 3.0 GHz processor (up to 3.3 GHz)

CPU Architecture

64-bit x86

Encryption Engine

 (AES-NI)

System Memory

128 GB RDIMM DDR4 ECC (8 x 16 GB)

Maximum Memory

4 TB (16 x 256 GB)

Memory Slot

16 x Long-DIMM DDR4

Flash Memory

5GB (Dual boot OS protection)

Drive Bay

24 x 2.5-inch U.2 PCIe NVMe

The system is shipped without SSD.

For the SSD compatibility list, please visit https://www.qnap.com/compatibility/

Drive Compatibility

2.5-inch U.2 NVMe Gen 3 x4 solid state drives

Hot-swappable

SSD Cache Acceleration Support

2.5 Gigabit Ethernet Port (2.5G/1G/100M)

2 (also support 10M)

25 Gigabit Ethernet Port

4 x 25GbE SFP28 SmartNIC port

Jumbo Frame

PCIe Slot

5

Slot 1: PCIe Gen4 x4

Slot 2: PCIe Gen4 x8 or x4

Slot 3: PCIe Gen4 x4

Slot 4: PCIe Gen4 x8

Slot 5: PCIe Gen4 x16 or x8

*Slot 4 and Slot 5 are preinstalled with 25GbE network adapters. Please reserve these slots for the 25GbE adapters for the best performance.

**Slot 2 provides the width of PCIe Gen4 x8 when Slot 3 is not in use, and provides the width of PCIe Gen4 x4 when Slot 3 is in use.

***Slot 5 provides the width of PCIe Gen4 x16 when Slot 4 is not in use, and provides the width of PCIe Gen4 x8 when Slot 4 is in use.

USB 3.2 Gen 1 port

2

Form Factor

Rackmount

LED Indicators

HDD, Status, 10 GbE, LAN, storage expansion port status

Buttons

Power, Reset

Dimensions (HxWxD)

88.3 × 480.97 × 510.23 mm

Weight (Net)

15.2 kg

Weight (Gross)

21.86 kg

Operating temperature

0 - 35°C (32°F - 95°F)

Storage Temperature

-20 - 70°C (-4°F - 158°F)

Relative Humidity

5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)

Power Supply Unit

1100W PSU(x2), 200-240Vac,

Max Wattage:

1100W@200-240Vac

850W@100-240Vac

Power Consumption: Operating Mode, Typical

277.64 W

Tested with drives fully populated.

Fan

4 x 60mm, 12VDC

Sound Level

53.5 db(A)

System Warning

Buzzer
