QNAP GM-1001

QNAP GM-1001

GM-1000 Gemini Series Intel® Xeon® E dual NAS with doubled performance: ZFS-based QuTS hero provides outstanding backup and hybrid cloud solutions

Call đ

QNAP GM-1001

THÔNG SỐ KỸ THUẬT GM-1001

CPU Intel® Xeon® E-2234 quad-core 3.6 GHz processor (burst up to 4.8 GHz) per node
CPU Architecture 64-bit x86
Floating Point Unit
Encryption Engine  (AES-NI)
Hardware-accelerated Transcoding
System Memory 8 GB UDIMM DDR4 (2 x 4 GB) per node
Maximum Memory 128 GB (4 x 32 GB) per node
Memory Slot 4 x Long-DIMM DDR4 per node
Flash Memory 5GB (Dual boot OS protection)
Drive Bay 8 x 3.5-inch + 2 x 2.5-inch per node
The system is shipped without HDD/SSD.
For the HDD/SSD compatibility list, please visit https://www.qnap.com/compatibility/
Drive Compatibility 3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives

2.5-inch bays:
2.5-inch SATA solid state drives
2.5-inch U.2 Gen3 x4 solid state drives
Hot-swappable
M.2 SSD Slot 2 x M.2 2280 NVMe Gen3 x2 slots per node
SSD Cache Acceleration Support
2.5 Gigabit Ethernet Port (2.5G/1G/100M) 2 per node (also support 10M)
10 Gigabit Ethernet Port 2 x 10GbE SFP+ SmartNIC (Mellanox ConnectX®-4 Lx EN)
Wake on LAN (WOL)
Jumbo Frame
PCIe Slot 2 per node
Slot 1: PCIe Gen3 x4 (PCH)
Slot 2: PCIe Gen3 x8 (CPU)
USB 3.2 Gen 2 (10Gbps) Port 4 x Type-A per node
Form Factor 3U Rackmount
LED Indicators HDD, SSD, Status, Power, Fan, Temperaure, Node ID
Buttons Power, Reset, OLED
Dimensions (HxWxD) 132.1 × 481.7 × 623.4 mm
Weight (Net) 25.21 kg
Weight (Gross) 34.45 kg
Operating temperature 0 - 40 °C (32°F - 104°F)
Storage Temperature -20 - 70°C (-4°F - 158°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit 770W(x2), 100-240V
Power Consumption: HDD Sleep Mode 169.68 W
Power Consumption: Operating Mode, Typical 201.07 W
Tested with drives fully populated.
Fan 3 x 60mm, 12VDC per node
Sound Level 45.6 db(A)
System Warning Buzzer
Max. Number of Concurrent Connections (CIFS) - with Max. Memory 10000
