QNAP TS-h973AX-8G 9 Bay, Thiết Bị Lưu Trữ NAS QNAP TS-h973AX-8G Chính Hãng

QNAP TS-h973AX-8G 9 Bay, Thiết Bị Lưu Trữ NAS QNAP TS-h973AX-8G Chính Hãng

"9-bay NAS, AMD Ryzen V1500B 4C 8T 2.2GHz, 8GB DDR4 SODIMM, 5 x 2.5""/3.5"" SATA 6Gbps + 2 x 2.5"" U.2 NVMe PCIe Gen3 x4 / 2.5"" SATA 6Gbps + 2 x 2.5"" SATA 6Gbps drive bays. 2 x 2.5GbE, 1 x 10GBASE-T Multi-Gig (10G/5G/2.5G/1G/100M), USB 3.2 Gen2 Type-A and Type-C, supports capacity expansion with QNAP TL and TR expansion Interface Enclosures". Hàng chính hãng CO-CQ đầy đủ, Cam kết giá tốt nhất thị trường!

Call đ

QNAP TS-h973AX-8G 9 Bay, Thiết Bị Lưu Trữ NAS QNAP TS-h973AX-8G Chính Hãng

THÔNG SỐ KỸ THUẬT THIẾT BỊ LƯU TRỮ MẠNG QNAP TS-h973AX-32G


CPU AMD Ryzen™ Embedded V1500B quad-core eight threads 2.2 GHz processor
CPU Architecture 64-bit x86
Floating Point Unit
Encryption Engine  (AES-NI)
System Memory 8 GB SO-DIMM DDR4 (1 x 8 GB)
Maximum Memory 64 GB (2 x 32 GB)
Memory Slot 2 x SO-DIMM DDR4
Support optional ECC memory
For dual-DIMM configuration, you must use a pair of identical DDR4 modules.
Flash Memory 5GB (Dual boot OS protection)
Drive Bay 5 x 3.5-inch + 4 x 2.5-inch
The system is shipped without HDD/SSD.
For the HDD/SSD compatibility list, please visit https://www.qnap.com/compatibility/
Drive Compatibility 3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives

2.5-inch bays:
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
2.5-inch U.2 NVMe PCIe Gen3 x4 solid state drives (2.5-inch Bay #1 & #2)
* 2.5-inch bay #1 & #2 support either U.2 NVMe SSDs or SATA 6Gb/s SSDs.
** U.2 NVMe solid-state drives can only be installed in 2.5-inch bay numbers 1 and 2. Installing these drives in other bays will damage the drive connectors.
Hot-swappable
SSD Cache Acceleration Support
2.5 Gigabit Ethernet Port (2.5G/1G/100M) 2
5 Gigabit Ethernet Port (5G/2.5G/1G/100M) Optional via the QNA-UC5G1T USB to 5GbE network adapter
10 Gigabit Ethernet Port 1 x 10GBASE-T (10G/5G/2.5G/1G/100M)
Wake on LAN (WOL)
Jumbo Frame
USB 3.2 Gen 2 (10Gbps) Port 1 x Type-C USB 3.2 Gen 2
3 x Type-A USB 3.2 Gen 2
Form Factor Tower
LED Indicators HDD 1-5, SSD 1-4, Power/Status, LAN, USB
Buttons Power, Reset, USB Copy
Dimensions (HxWxD) 182.65 × 224.6 × 224.1 mm
Weight (Net) 3.52 kg
Weight (Gross) 5.12 kg
Operating temperature 0 - 40 °C (32°F - 104°F)
Storage Temperature -20 - 70°C (-4°F - 158°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit External, 120 W, AC 100 to 240 V
Power Consumption: HDD Sleep Mode 41.2 W
Power Consumption: Operating Mode, Typical 55.41 W
Tested with drives fully populated.
Fan 1 x 140mm, 12VDC
Sound Level 22.9 db(A)
System Warning Buzzer
Kensington Security Slot
Max. Number of Concurrent Connections (CIFS) - with Max. Memory 2000
