12-bay 2U Rackmount SATA JBOD expansion unit, redundant PSU, with a QXP-1600eS PCIe SATA host card and 3 SFF-8088 to SFF-8644 SAS/SATA 6Gb/s external cables. Hàng chính hãng CO-CQ đầy đủ, Cam kết giá tốt nhất thị trường!
THÔNG SỐ KỸ THUẬT QNAP TL-R1200S-RP
| Drive Bay | 12 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility | 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Audio Alert On/Off Switch | |
| Form Factor | 2U Rackmount |
| Host Interface | 3 x SFF-8088 |
| LED Indicators | HDD 1-12, Status, Link, Fan error |
| Buttons | Power switch |
| Dimensions (HxWxD) | 88.6 × 482 × 562.5 mm |
| Weight (Net) | 9.49 kg |
| Weight (Gross) | 12.77 kg |
| Max. number of HDDs/SSDs supported | 12 |
| Hard Drive Type | 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Operating temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit | 250W(x2) PSU, 100 - 240V |
| Power Consumption: Operating Mode, Typical | 73.7 W
Tested fully polulated with Seagate ST6000NM0024 hard drives.
|
| Fan Mode Switch | (Auto, high, medium, low) |
| Fan | 2 x 70mm, 12VDC |
| Sound Level | 33.7 db(A) |
| System Warning | Buzzer |
| Kensington Security Slot |
