"16-bay 3U rackmount SAS 12Gbps JBOD dual controller expansion enclosure with SAS expander, 2.5""/3.5"" SAS 12Gbps drives (2.5"" SATA 6Gbps drives with optional QDA-SA2 accessory), 3 x SFF-8644 Mini-SAS HD SAS 12Gbps ports per controller, redundant PSU, without rail kit." Hàng chính hãng CO-CQ đầy đủ, Cam kết giá tốt nhất thị trường!
THÔNG SỐ KỸ THUẬT QNAP QNAP TL-R1620Sdc
| Drive Bay | 16 x 3.5-inch SAS 12Gb/s, SAS/SATA 6Gb/s
The system is shipped without HDD.
For the HDD compatibility list, please visit https://www.qnap.com/compatibility/ |
| Drive Compatibility | 3.5-inch bays: 3.5-inch SAS hard disk drives 2.5-inch SAS hard disk drives 2.5-inch SAS solid state drives |
| Hot-swappable | |
| Gigabit Ethernet Port (RJ45) | 1
For console access and CLI.
|
| Form Factor | 3U Rackmount |
| Host Interface | 3 x 12Gb/s SAS 3.0 wide ports (4-wide port) Mini-SAS HD (SFF-8644) for each controller |
| LED Indicators | HDD 1-16, Status, Power, Fan, Temperature, SAS connector status |
| Buttons | Power, OLED |
| Dimensions (HxWxD) | 131.3 × 482.2 × 425.3 mm |
| Weight (Net) | 12.26 kg |
| Weight (Gross) | 18.04 kg |
| Max. number of HDDs/SSDs supported | 16 |
| Hard Drive Type | 3.5" or 2.5" SAS12Gb/s 6Gb/s drives |
| Operating temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit | 550W(x2), 100-240V |
| Power Consumption: Operating Mode, Typical | 212.24 W
Tested with drives fully populated.
|
| Fan | 3 x 80mm, 12VDC |
| Sound Level | 28.8 db(A) |
| System Warning | Buzzer |
| Management | Managed via NAS QES OS and JBOD Manager for Windows |
