TS-328

CPU

Realtek RTD 1296 ARM® Cortex-A53 quad-core 1.4 GHz processor

CPU Architecture

64-bit ARM

Floating Point Unit

ü

Encryption Engine

ü

Hardware-accelerated Transcoding

, up to 1080P

System Memory

2 GB DDR4 RAM, not expandable

Note: Reserves some RAM for use as shared graphics memory.

Maximum Memory

2 GB DDR4 RAM, not expandable

Flash Memory

4 GB (Dual boot OS protection)

Drive Bay

3 x 3.5-inch SATA 6Gb/s, 3Gb/s

bundled one 2.5" tray base for installing 2.5" HDD/SSD; additional purchase can be made from QNAP shop

Drive Compatibility

3.5-inch bays:

3.5-inch SATA hard disk drives

2.5-inch SATA hard disk drives

2.5-inch SATA solid state drives

A 2.5" drive tray base (TRAY-25-NK-BLK03) is needed to install a 2.5" SSD/HDD

Hot-swappable

ü

Gigabit Ethernet Port (RJ45)

2

Note: You can set the MTU of LAN 1 up to 1500 while the MTU of LAN 2 can be set up to 9000.

Wake on LAN (WOL)

ü

Jumbo Frame

ü

USB 2.0 port

1

USB 3.2 Gen 1 port

2

Audio Output

1 x built-in speaker, 1 x 3.5mm line out jack (for amplifiers or speakers)

You cannot use the speakers and the line-out jack simultaneously.

Form Factor

Tower

LED Indicators

System Status, LAN, USB, HDD1~3

Buttons

Power, Reset, USB Copy

Dimensions (HxWxD)

142 × 150 × 260.1 mm

Weight (Net)

1.64 kg

Weight (Gross)

2.69 kg

Operating temperature

0 - 40 °C (32°F - 104°F)

Storage Temperature

-20 - 70°C (-4°F - 158°F)
